Stem
Alloy Trail Stem, 35mm bar bore
Saddle
Body Geometry Bridge Saddle, steel rails
Tape
Specialized Trail Grips
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
SeatPost
TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm
Seat Binder
Alloy, 38.6mm
Frame
FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
Spokes
DT Swiss Industry
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub
Specialized alloy front hub disk, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Inner Tubes
Standard, Presta Valve
Wiring Harness
Custom Specialized wiring harness
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Motor
Specialized 2.2, Custom Rx Trail Tuned Motor
Battery
Specialized M3-500A, Integrated battery, 500Wh
UI/Remote
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Crankset
Praxis Forged/Custom Offset/ISIS Spindle Interface, 160mm
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Chain
SRAM NX Eagle, 12-speed
Shift Levers
SRAM SL SX Eagle, 12-speed
Rear Derailleur
SRAM SX Eagle, 12-speed
Chainrings
SRAM X-Sync Eagle, 104 BCD, 34T, steel
Rear Shock
RockShox Deluxe Select R, rebound adjust, S1: 52.5x210mm, S2-S6: 55x210mm
Fork
Rockshox 35 Silver 29, Turnkey damper, S1: 150mm travel, S2-S6: 160mm travel
Rear Brake
SRAM G2 RE, 200mm
Front Brake
SRAM G2 RE, S1-S3: 200mm, S4-S6: 220mm
Weight
23.4kg (51 lb, 9.4 oz)
Weight Size
S4
